Huaerda Direct Sales 180℃ EIW 0.90mm for Medical Imaging Equipment Insulation Winding Wire Enameled Wire Electrical Wires Cable
Description
Key attributes
| Conductor Material | Bare Copper | Diameter | 0.900mm |
| Insulation Material | Polyester imide paint | Rated voltage | 5000V |
| Place of Origin | Jiangxi,China | Model Number | EIW |
| Brand Name | HUAERDA | Application | Industrial motors andelectrical equipment |
| Conductor Type | Solid | Shape | Round |
| Temperature | 180℃ | Type | Insulated |
Packaging and delivery
| Selling Units | kilogram |
The HUAERDA Direct Sales 180℃ EIW 0.90mm Enameled Wire is a reliable and high-quality insulation winding wire designed specifically for medical imaging equipment. Made with precision and care, this wire is essential for ensuring the safety and efficiency of electrical components in sensitive medical devices
HUAERDA has built a strong reputation for producing durable and efficient electrical wires, and this 0.90mm enameled wire is no exception. It is made to withstand temperatures up to 180℃, which makes it suitable for use in environments where heat resistance is crucial, such as inside MRI machines, X-ray machines, and other medical imaging equipment. This temperature rating ensures the wire maintains its performance without breaking down or losing its insulating properties, even under continuous or heavy operation
The 0.90mm diameter of the wire strikes a great balance between strength and flexibility. It is thick enough to carry electrical current safely while still being easy to handle and wind during the manufacturing or repair process. This flexibility helps technicians achieve neat and precise winding, which is important for the compact and complex components inside medical imaging devices
The enamel coating on the wire provides excellent insulation, preventing electrical shorts and protecting the equipment from potential damage caused by electrical faults. This insulation also helps improve the overall efficiency and reliability of the equipment by reducing energy loss and ensuring steady electrical flow
HUAERDA’s commitment to quality means that each batch of wire undergoes strict testing to meet industry standards, ensuring consistency and safety for all users. This makes the 180℃ EIW 0.90mm enameled wire a trusted choice for manufacturers and service providers working with sensitive medical imaging equipment
In addition to medical imaging devices, this wire can also be used in other electrical applications where high-temperature resistance and reliable insulation are required, making it a versatile product for various electrical and electronic industries
The HUAERDA Direct Sales 180℃ EIW 0.90mm enameled wire is a strong, flexible, and heat-resistant insulation winding wire. It is specifically made to meet the demanding needs of medical imaging equipment, ensuring safety, durability, and optimal performance. Choosing HUAERDA means choosing quality and reliability for your electrical wiring needs
Type |
Polyester |
Modified Polyester |
Polyurethane |
Polyurethane |
Polyesterimide |
Polyamide-imide |
Code |
PEW, QZ |
PEW, QZ |
UEW, QA |
UEW, QA |
EIW, QZY |
EI/AIW, QZY/XY |
Thermal Class |
Class B, 130℃ |
Class F, 155℃ |
Class F, 155℃ |
Class H, 180℃ |
Class H, 180℃ |
Class H, 200℃/220℃ |
1. Q: How fine can the minimum diameter of enameled wire be
A: The smallest diameter of enameled wire we produce can be up to 0.060 mm. We adopt intelligent process control to ensure that excellent insulation and high temperature resistance can still be maintained under the demand of high precision, which is widely used in the fields of clicks, electrical appliances, new energy vehicles, 5G communication and so on
2. Q: How to ensure the quality stability of enameled wire
A: We monitor the process parameters in real time through the intelligent production system, and have a number of national invention patents and utility model patented technologies. For example, the multilayer composite enameled wire for 5G communication solves the problem of coating adhesion and has a domestic market share of over 11.2%
3. Q: Do the conductor materials meet high standards
A: We use annealed low-oxygen and oxygen-free copper wires, which are superior to ordinary copper in terms of oxidation resistance and conductivity, and have passed industry certification. For example, the purity of the conductor is 99.97%, which ensures low resistance and low heat generation in long-term use
4. Q: How long is the lead time for order delivery
A: For stock, we can ship the goods to the port of loading within 7 working days after we receive the deposit. For production period, it usually takes about 15 days to 30 days to ship the goods to the port of loading after we receive the deposit
5. Q: How to deal with quality problems
A Please keep the product samples and contact customer service
6. Q: Why do I buy enameled wire with many pinholes in the salt water test
A: The national standard stipulates that the correct way to take samples for testing is that the specimen should not be subjected to tension or unnecessary bending when it is removed from the package. Before each test, enough enameled wire should be removed to ensure that the specimen does not contain damaged wire segments. Dry never bend yo
7. Q: Why is the resistance tested, greater than the specified range
A: The national standard specifies the resistance test environment of 20 ℃, the southern region of the basic test time is more than 30 ℃ high temperature weather, and the general customer themselves do not have a constant temperature laboratory, so the test results will be high. Or according to the temperature index converted to 20 ℃ resistance
8. Q: Why is there a color difference between the two batches of products
A: Enameled wire is the main pursuit of product performance, the color of small differences do not affect the quality, please rest assured that the use
9. Q: During the use of fine wire, there will be many threads and can't find the threads
A: The stretching force of fine thread is relatively poor, easy to break the thread. Just need to hand all the thread together (can not find the thread of the surface of the thread pulled off some), the surface of the waste line slowly gathered, remove some waste line, and finally will become a thread. Finding the thread is to remove some of the waste line, rest assured boldly collect, do not shrink yo
